Solid Side Utility

Arctic Wire Harness
All our wire harnesses are sealed and the front hook up is rated for -65°F.
Pressure Treated Pine Floor
All our lumber is made and installed to withstand weather.
Premium Components
We use brand name quality products for anything we don't produce in house.
3 Year Structural Warranty
All our frames are built tough and we back them up with a 3 year warranty.
Premium Powder Coat
We metal blast and apply a super durable powder coat.

Full specs & options

3K Sizes & Payload
Size - Weight - Payload
  • 77" x 12' - 1,520 lbs - 1,980 lbs
  • 77" x 14' - 1,630 lbs - 1,870 lbs
  • 83" x 12' - 1,565 lbs - 1,935 lbs
  • 83" x 14' - 1,720 lbs - 1,780 lbs
5.2K Sizes & Payload
Size - Weight - Payload
  • 77" x 12' - 1,545 lbs - 3,655 lbs
  • 77" x 14' - 1,655 lbs - 3,545 lbs
  • 83" x 12' - 1,585 lbs - 3,615 lbs
  • 83" x 14' - 1,740 lbs - 3,460 lbs
7K Sizes & Payload
Size - Weight - Payload
  • 77" x 12' - 1,730 lbs - 5,270 lbs
  • 77" x 14' - 1,880 lbs - 5,120 lbs
  • 77" x 16' - 2,020 lbs - 4,980 lbs
  • 3" x 12' - 1,760 lbs - 5,240 lbs
  • 83" x 14' - 1,925 lbs - 5,075 lbs
  • 83" x 16' - 2,080 lbs - 4,920 lbs
10K Sizes & Payload
Size - Weight - Payload
  • 77" x 12' - 1,925 lbs - 8,075 lbs
  • 77" x 14' - 2,070 lbs - 7,930 lbs
  • 77" x 16' - 2,080 lbs - 7,920 lbs
  • 83" x 12' - 1,955 lbs - 8,045 lbs
  • 83" x 14' - 2,115 lbs - 7,885 lbs
  • 83" x 16' - 2,145 lbs - 7,855 lbs
Brakes & Suspension
7K Standard
  • 3.5K Easy Lube Idler Spring Axle & Electric Brake Spring Axle
7K Options to Exchange or Add On
  • 3.5K Easy Lube Electric Brake Spring Axles
10K Standard
  • 5.2K Easy Lube Idler Spring Axle & Electric Brake Spring Axle
10K Options to Exchange or Add On
  • 5.2K Easy Lube Electric Brake Spring Axles
Tires
3.5K Standard
  • 205/75 R15 (C) 6Ply Tires
3.5K Options to Exchange or Add On
  • Spare Tire Mount
  • Spare Tire
5K Standard
  • 225/75 R15 (D) 8Ply Tires
5K Options to Exchange or Add On
  • 235/80 R16 (E) 10Ply Tires
  • Spare Tire Mount
  • Spare Tire
7K Standard
  • 205/75 R15 (C) 6Ply Tires
7K Options to Exchange or Add On
  • Spare Tire Mount
  • Spare Tire
10K Standard
  • 235/80 R16 (E) 10Ply Tires
10K Options to Exchange or Add On
  • Spare Tire Mount
  • Spare Tire
Frame
Standard
  • 24" Spaced Crossmembers
  • Straight Deck
  • Smooth Fenders
  • Treated Yellow Pine Floor
  • 4" Channel Frame
  • Solid Side Rails with Tarp Hooks
  • Wrap Tongue
Options to Exchange or Add On
  • None Available
Hitch
3.5K Standard
  • 2" 10K Demco Adjustable Cast Iron Coupler
3.5K Options to Exchange or Add On
  • 2-5/16" 21K Demco Adjustable Cast Iron Coupler
5K Standard
  • 2" 10K Demco Adjustable Cast Iron Coupler
5K Options to Exchange or Add On
  • 2-5/16" 21K Demco Adjustable Cast Iron Coupler
7K Standard
  • 2" 10K Demco Adjustable Cast Iron Coupler
7K Options to Exchange or Add On
  • 2-5/16" 21K Demco Adjustable Cast Iron Coupler
10K Standard
  • 2-5/16" 21K Demco Adjustable Cast Iron Coupler
10K Options to Exchange or Add On
  • 3" 25K Adjustable Pintle Eye Coupler
Jack
Standard
  • 2K Top-Wind Flip Jack
Options to Exchange or Add On
  • 7K Drop Leg Jack
Cargo Loading
Standard
  • 4' Spring Assisted Lay-Down Gate
  • Standard Stake Pockets
Options to Exchange or Add On
  • Lockable Fuel Can Rack
  • Front Tool Box
  • 24" x 24" Tool Cage
  • Lockable Trimmer Rack
  • Water Cooler Rack
Electrical
Standard
  • Led Lights
  • Weather Resistant Harness (-65°F)
Options to Exchange or Add On
  • None Available
Loading Angles
Standard
  • Straight Deck with 4' Gate - 24°
Options to Exchange or Add On
  • None Available
Color
Standard
  • Lamar Charcoal Gray Powder Coat
Options to Exchange or Add On
  • None Available

Have a Question?

01

"How often do I need to torque my lug nuts?"

After 50 miles, you need to check your lug nuts and torque them to the right specs.
02

"How should I load my trailer?"

Keeping your trailer load properly distributed is very important. Always load heavier towards the tongue. At least 60% of your payload must be forward of the trailer center, with lighter items on the top and rear. Secure everything with proper tie downs.
03

"What kind of warranty do Lamar trailers come with?"

We have a three-year frame warranty and a one-year component warranty. Tire warranty is handled by our tire manufacturer; check the sticker on the front of your trailer for contact information.
04

"What is the payload on Lamar Trailers?"

We have all our weights and payloads listed. Check out individual products here on our website to see details on the trailer you're interested in.
05

"I'm having trouble with my trailer! What should I do?"

Warranty claims are handled through our dealers. They are able to look at any issues firsthand and have them fixed in-house or outsourced by local reputable businesses. Bring your trailer into your local Lamar dealer. If this is not an option, you can email us directly with your VIN, pictures, and a description of the issue at warranty@lamartrailers.com. Any unauthorized work will not be reimbursed.
06

"What is causing my trailer's tire wear?"

Tire wear should be checked frequently. Once a tire wear pattern is established, stopping becomes difficult, even when the underlying cause is corrected. Tire pressure should always be in accordance with the manufacturer's recommended pressure rating for any given load.

1. Always check tire pressure cold before operation.

2. Do not bleed air from tires when they are hot.
07

"I scratched my trailer, where can I get touch up paint?"

Our charcoal gray color is a close match to the Rustoleum Gloss Charcoal rattle can available at most hardware stores.
08

"My hydraulic reservoir is flooding; how can I fix it?"

Typically, an overflowing reservoir is caused by a low battery.

On a low battery, the cylinder will push air instead of fluid into the cylinder, causing the fluid to be pushed out into the reservoir.

Charge the battery on your dump or tilt trailer or replace it and cycle the dump up and down to see if the oil will go down.
09

"Where is my trailer VIN on my Lamar Trailer?"

Your VIN sticker is usually located on the inside of your trailer tongue.
10

"How do I grease my trailers axles?"

If your trailer has grease axles, we recommend re-greasing them once a year or every 12,000–36,000 miles. Jack up the trailer, remove the hub grommet, and use a manual grease gun on the grease zerk (pneumatic guns can damage seals). Slowly spin the wheel while adding grease until new grease appears, then stop. Wipe off the excess, replace the grommet, and repeat on all axles.
11

"What hydraulic fluid do I need for my trailer's hydraulic pump?"

If you are looking to fill up or replace the hydraulic fluid in the hydraulic pump on your Lamar trailer, you should replace it with AW-32.

You can find AW-32 Fluid at any local trailer dealership, Home Depot, Lowes, or local parts stores like Advanced Auto Parts, O'Reillys, or Auto Zone.
